Spindle power : 7.5 kW, 10 hp
Water supply : 30 l/mm > mini 2 bars,7.9 gal(US)/mn > min 29 PSI
Air supply : 15 m3/h > 6 bar, 494.4 ft3/h > 87 PSI
Power supply : 40 kW / 50 hp , 400 - 480 V , 50 - 60 Hz
Longitudinale stroke : 1700 mm, 62.93"
Wheels : 3 x Ø 1000 mm, 2 x 3.28"
Clamping : Pneumatic press
Wire tension : Pneumatic
Axis movement : Brushless motor
Cutting capacity : Ø 570 mm x 3000 mm, Ø 22.44" x 118.11"
Cable length : 8 m, 26.25’
Table rotation : 360°
Vertical capacity : 400 mm, 15.75"
All-in dimensions : 5300 x 3800 x 3100 mm, 208.6 x 149.6 x 122"
Weight : 3300 kg
